APPENDIX C
IEC 61850
The CoreSense M10 implements an IEC 61850 MMS server over TCP/IP Ethernet that is compliant with
edition 1 of the IEC 61850 standard.
PIXIT Protocol Implementation eXtra Information for Testing
MICS Model Implementation Conformance Statement
PICS Protocol Implementation Conformance Statement
TICS Technical Issues Implementation Conformance Statement
CoreSenseStrict.icd ICD file which does not contain extended data attributes
CoreSenseExtended.icd ICD file which contains extended data attributes
For your convenience, selected information is available in this appendix.
PIXIT
PIXIT for Association Model
ID ED Description Value/Clarification
As1 1 Maximum number of clients that can set-up an association
simultaneously
2
As2 1.2 TCP_KEEPALIVE value. The recommended range is 1..20 s 5 seconds
As3 1,2 Lost connection detection time 5 sec (idle) + (5 sec * 5 retry) = 30
seconds
As4 - Authentication is not supported yet NA
As5 1,2 What association parameters are necessary for successful
association
Transport selector Y
Session selector Y
Presentation selector Y
AP Title N
AE Qualifier N
As6 1,2 If association parameters are necessary for association,
describe the correct values e.g.
Transport selector 00 01
Session selector 00 01
Presentation selector 00 00 00 01
AP Title NA
AE Qualifier NA
As7 1,2 What is the maximum and minimum MMS PDU size Max MMS PDU size 120000
bytes
Min MMS PDU size 1200 bytes
