C66 User Guide
PIXIT for Setting Group Control Model
ID ED Description Value/Clarification
Sg1 1 What is the number of supported setting groups for each logical device SG is not supported.
Sg2 1,2 What is the effect of when and how the non-volatile storage is updated
(compare IEC 61850-8-1 $16.2.4)
SG is not supported.
Sg3 1 Can multiple clients edit the same setting group SG is not supported.
Sg4 1 What happens if the association is lost while editing a setting group SG is not supported.
Sg5 1 Is EditSG value 0 allowed SG is not supported.
Sg6 2 When ResvTms is not present how long is an edit setting group locked SG is not supported.
PIXIT for Reporting Model
ID ED Description Value/Clarification
Rp1 1 The supported trigger conditions are
(compare PICS)
Integrity Y
Data change Y
Quality change Y
Data update Y
General interrogation Y
Rp2 1 The supported optional fields are Sequence-number Y
Report-time-stamp Y
Reason-for-inclusion Y
Data-set-name Y
Data-reference Y
Buffer-overflow N
EntryID N
Conf-rev Y
Segmentation N
Rp3 1,2 Can the server send segmented reports No
Rp4 1,2 Mechanism on second internal data change
notification of the same analogue data value within
buffer period (Compare IEC 61850-7-2 $14.2.2.9)
Send report immediately
Rp5 1 Multi-client URCB approach
(compare IEC 61850-7-2:2003 $14.2.1)
Each URCB is visible to all clients
Rp6 - What is the format of EntryID Deprecated
Rp7 1,2 What is the buffer size for each BRCB or how many
reports can be buffered
BRCB are not supported.
Rp8 - Pre-configured RCB attributes that are dynamic,
compare SCL report settings
Deprecated
Rp9 1 May the reported data set contain: -structured data objects? Y
-data attributes? Y
R10 1,2 What is the scan cycle for binary events
Is this fixed, configurable
100 ms
Fixed
