IEC 61850 C69
PIXIT for GOOSE Performance
ID ED Description Value/Clarification
Gf1 1,2 Performance class GOOSE not supported.
Gf2 1,2 GOOSE ping-pong processing method GOOSE not supported.
Gf3 1,2 Application logic scan cycle (ms) GOOSE not supported.
Gf4 1 Maximum number of data attributes in GOOSE
dataset (value and quality has to be counted as
separate attributes)
GOOSE not supported.
PIXIT for Control Model
ID ED Description Value/Clarification
Ct1 1 What control models are supported
(compare PICS)
DOns N
SBOns N
DOes N
SBOes N
Ct2 1,2 Is the control model fixed, configurable and/or
dynamic
Fixed
Ct3 - Is TimeActivatedOperate supported (compare PICS or
SCL)
Deprecated
Ct4 1,2 Is “operate-many” supported (compare sboClass) N
Ct5 1 Will the DUT activate the control output when the test
attribute is set in the SelectWithValue and/or Operate
request (when N test procedure Ctl2 is applicable)
N
Ct6 - What are the conditions for the time (T) attribute in
the SelectWithValue and/or Operate request
Deprecated
Ct7 - Is pulse configuration supported (compare
pulseConfig)
Deprecated
Ct8 1 What is the behavior of the DUT when the check
conditions are set
Is this behavior fixed, configurable, online changeable
Synchrocheck N
Interlock-check N
Not applicable
