3.5.3 Function test of three-position enabling device
Performing the function test
NoteAction
Start the robot system and turn the mode
switch to manual mode.
1
This test is passed if the event message
"10011 Motors ON state" appears in the
FlexPendant log.
Press the three-position enabling device
to the middle position and then hold the
enabling device in this position.
2
If the event message "10011 Motors ON
state" does not appear or if the event
message "20224 Enabling device conflict"
appears in the FlexPendant log, the test is
failed and the root cause of the failure must
be found.
This test is passed if the event message
"10012 safety guard stop state" appears
in the FlexPendant log.
While still holding the three-position en-
abling device pressed, press the enabling
device harder to the enable the device's
third position.
3
If the event message "10012 safety guard
stop state" does not appear or if the event
message "20224 Enabling device conflict"
appears in the Flexpendant log, the test is
failed and the root cause of the failure must
be found.
120 Product manual - IRC5 Compact
3HAC047138-001 Revision: G
© Copyright 2009-2017 ABB. All rights reserved.
3 Maintenance
3.5.3 Function test of three-position enabling device
