4.14 Replacement of contactor unit
Location
The following illustration shows the location of the contactor unit in IRC5 Compact.
A
xx1400002008
Contactor unitA
Required equipment
NoteEquipment
Contactor ASL16-30-10 DC24VContactor unit
See Miscellaneous parts on page 212.
See Circuit diagrams on page 217.Circuit diagram
Removal
The following procedure describes how to remove the backup energy bank.
Note/illustrationAction
DANGER
Before commencing any work inside the
cabinet, please observe the safety informa-
tion in section DANGER - Make sure that the
main power has been switched off! on
page 33.
1
Continues on next page
Product manual - IRC5 Compact 173
3HAC047138-001 Revision: G
© Copyright 2009-2017 ABB. All rights reserved.
4 Repair
4.14 Replacement of contactor unit
