Note/illustration
Action
xx0900000366
Connect
the
wires
according
to
the
illustration.
Use
a
screwdriver
to
make
the
contact
tight.
3
For
single
phase:
•
X0.1
-
power
line
•
X0.2
-
zero
line
•
X0.PE
-
earth
wire
Assemble
the
connector
by
fitting
the
hood
and
the
female
connector,
and
tighten
the
screws.
4
Product
manual
-
IRC5
Compact
75
3HAC047138-001
Revision:
G
©
Copyright
2009-2017
ABB.
All
rights
reserved.
2
Installation
and
commissioning
2.6.6
Fitting
the
connector
Continued
74
76
