ABB SACE Emax 2 Installation, Operation And Maintenance Instructions

ABB | SACE Emax 2
Putting into service and maintenance | 3 - Maintenance
99 | © 2014 ABB | 1SDH000999R0002 - L8569
Circuit-breaker life
Emax 2 circuit-breakers, with or without opening or closing coils, can withstand the following operating
cycles if regularly serviced
(1)
.
circuit-
breaker IEC
60947
Interrup
-
ted rated
current
Mechanical life with
regular maintenance
Electrical life
440V AC 690V AC
Frequency of
Operations/
hourIu (40°C) [A]
No. opera
-
tions (x 1000)
Frequency of
Operations/
hour
No. opera
-
tions (x 1000)
No. opera
-
tions (x 1000)
E1.2
< 1250 25 60 15 15 30
1600 25 60 12 10 30
2000 25 60 10 8 30
2500 20 60 8 7 30
circuit-
breaker UL
1066
Interrup
-
ted rated
current
Mechanical life with
regular maintenance
Electrical life
635V AC 508V AC
Frequency of
Operations/
hourIu (40°C) [A]
No. opera
-
tions (x 1000)
Frequency of
Operations/
hour
No. opera
-
tions (x 1000)
No. opera
-
tions (x 1000)
E1.2-A
< 800 20 60 6.5 7 30
1200 20 60 8 8 30
(1)
See chapter 5 - Environmental conditions on page 21 .
Maintenance schedule
Proper maintenance of the equipment allows good electromechanical operation to be maintained over time.
The maintenance plan for SACE Emax 2 circuit-breakers specifies the maintenance frequency for the different
types of site conditions.
We include the table indicating the frequency with which maintenance should be carried out and the relative
routine maintenance operations required.
Maintenance in standard envi-
ronments
(1)
Maintenance in dusty environments
(dust level measured > 1mg/m3)
Frequency
One year or 2000 operations or after trip
-
ping on short circuit
6 months or 1000 operations or after trip-
ping on short circuit
(1)
See chapter 5 - Environmental conditions on page 21 .
Compliance with the following rules is also recommended:
• Even circuit-breakers that are operated infrequently or that remain closed or open for long periods of time
must be subjected to programmed maintenance.
• All the circuit-breakers provide information on the number of operations performed in the presence of
auxiliary power supply of the Trip Unit. With Ekip Dip releases, the information can be obtained with the
aid of Ekip T&P and a PC on which the Ekip Connect software is installed. With Ekip Touch releases, the
information is available at any time on the appropriate display. With Ekip Dip releases, installation of the
mechanical operation counter is recommended (supplied on request).
• During the service, visually inspect the circuit-breaker from the outside to check for the presence of dust,
dirt or damage.

ABB SACE Emax 2 Specifications

General

Type	Air circuit breaker
Rated Current	800 A to 6300 A
Breaking Capacity	Up to 150 kA at 415 V AC
Frequency	50/60 Hz
Number of Poles	3, 4
Installation	Fixed or withdrawable
Standards	IEC 60947-2
Trip Unit	Ekip Touch, Ekip Hi-Touch
Communication	Modbus, Profibus, Ethernet
