ABB | SACE Emax 2
Introduction to Ekip protection releases | 1 - Presentation
33 | © 2014 ABB | 1SDH000999R0002 - L8569
Integrated functions: Self-
diagnosis, Test and Power
Controller
All the protection releases for Emax 2 integrate:
• Self-diagnosis: continuous monitoring of the state of the internal and external connections, with signalling
of any faults that may occur.
• Test: checking of the protections and the other functionalities.
In addition, releases of the Ekip Touch series can be supplied equipped with Power Controller to regulate the
energy demand.
Dip Touch
Self-diagnosis
Test
Power Controller
DISTRIBUTION GENERATORS
Dip Touch Hi-Touch G Touch G Hi-Touch
The self-diagnosis and test functions for Ekip DIP are available starting from page 45.
Accessorizing modules
The Emax 2 circuit-breakers and Ekip releases can be accessorized as indicated in the combination tables
on page 52.
Various types of modules are available, differing in functionality and the position in which they are mounted
on the circuit-breaker.
The modules available for the terminal box of the circuit-breaker are:
Name Description Page
Ekip Supply Power supply module. 61
Link Communication module 63
The modules external to the circuit-breaker are:
Name Description Page
Ekip Signalling 10K Signalling module. 70
The supervision, configuration and reporting functions are, in addition, guaranteed by further modules for
temporary power supply and communication (test modules):
Name Description Page
Ekip TT Power supply and test module 69
Ekip T&P Power supply, communication and test module 68
Ekip Programming
Power supply, communication and programming
module.
68
Ekip Bluetooth Power supply and communication module 68
