ABB | SACE Emax 2

Ekip Dip protection release | 1 - Operator interface

iTest pushbutton

The iTest push-button is useful for three operations:

• Perform tests (circuit-breaker opening test and led test).

• Reset the signal for intervention of the protection as a result of a trip.

• With the release off, check the information relating to the switch-off or tripping event.

NOTE: pressing iTest with the release off, for approximately 4 seconds switches on:

• The power led, if the release is off due to an energy drop (primary current less than the minimum

level of operation, removal of auxiliary power supply with air circuit-breaker, etc…).

• The protection tripped LED if the release is off due to a protection trip.

Test connector

The test connector allows the connection of Ekip TT, Ekip T&P and Ekip Bluetooth modules, in order to

perform the following operations:

• Temporary energizing of the release to check the status, and perform the trip test (option possible with

all the front interface modules).

• Analysis, supervision and setting of additional parameters through external communication test units (Ekip

T&P, Ekip Bluetooth).
