ABB SACE Emax 2 Installation, Operation And Maintenance Instructions

ABB | SACE Emax 2
88 | © 2014 ABB | 1SDH000999R0002 - L8569
Mechanical accessories | 3 - Mechanical Interlocks
3 - Mechanical Interlocks
Mechanical interlocks determine the opening/closing logic between two circuit-breakers.
The type A interlock is available, usable in both the fixed version and the withdrawable version.
Mechanical interlock of type A -
Two Circuit-breakers
1 2
O
I
O
O
O
I
The Type A interlock is applicable to two circuit-breakers (normal power supply + emergency power supply).
It allows you never to have two circuit-breakers in the closed position at the same time.
Information on assembly is available at the web site http://www.abb.com/abblibrary/DownloadCenter/, in
particular with the sheets kit:
• 1SDH000999R0720 for interlock between E1.2circuit-breakers
• 1SDH000999R0721 for interlock between an E1.2 circuit-breaker and E2.2, E4.2 or E6.2 circuit-breaker

ABB SACE Emax 2 Specifications

General

Type	Air circuit breaker
Rated Current	800 A to 6300 A
Breaking Capacity	Up to 150 kA at 415 V AC
Frequency	50/60 Hz
Number of Poles	3, 4
Installation	Fixed or withdrawable
Standards	IEC 60947-2
Trip Unit	Ekip Touch, Ekip Hi-Touch
Communication	Modbus, Profibus, Ethernet
