ABB SACE Emax 2 Installation, Operation And Maintenance Instructions

ABB | SACE Emax 2
Emax E1.2 circuit-breakers | 2 - Transport and checking on receipt
7 | © 2014 ABB | 1SDH000999R0002 - L8569
2 - Transport and checking on receipt
Introduction
The Emax 2 circuit-breakers, on account of their weight, require special attention during transport and
handling.
They are distributed with following packages:
• single package for fixed circuit-breaker
• two packages for withdrawable circuit-breakers (one package for the fixed part and one for the mobile part).
The following notes regard transport, handling and storage.
Weight of the circuit-breakers
with packaging
The following table specifies the weights of the circuit-breakers with packaging:
Fixed
Moving part of withdra-
wable device
Fixed part of withdrawa-
ble device
III IV III IV III IV
E1.2
16 Kg / 35
lbs
18 Kg / 39
lbs
20 Kg / 44
lbs
23 Kg / 51
lbs
23 Kg / 51
lbs
26 Kg / 57
lbs
E1.2-A
16 Kg / 35
lbs
18 Kg / 39
lbs
22 Kg / 48
lbs
25,5 Kg / 56
lbs
24 Kg / 52
lbs
27 Kg / 59
lbs
NOTE:
• weights are indicated with reference to the basic circuit-breakers including protection release
and its sensors, without terminals and without accessories.
• the weights of the fixed part of withdrawable circuit-breakers refer to the version with horizontal
rear terminals.
Transport of the packaged
circuit-breaker
Consult the table "Weight of the circuit-breakers with packaging" before proceeding with the transport.
WARNING! Improper lifting can result in death, serious injury to persons and damage to the
equipment. Never lift a circuit-breaker and / or a fixed part above other people.
IMPORTANT: The trained personnel in charge of handling and lifting must use appropriate
safety equipment.
