Introduction to Ekip protection releases | 1 - Presentation
Protections
Numerous protection functions are available to protect the circuit-breaker in abnormal conditions of the
installation. The combination of the protection functions varies depending on the type of release, as shown
in the following table:
Dip Touch Hi-Touch G Touch G Hi-Touch
DISTRIBUTION GENERATORS
Dip Touch
P. Dip P. Touch
P. Measuring
Pro
P. Touch
P. Measuring
Pro
P. Hi-Touch
P. Touch
P. Measuring
Pro
P. G Touch
P. Touch
P. Measuring
Pro
P. Hi-Touch
P. G Touch
P. G Hi-
Touch
External toroid
S.G.R. Rc
DIP protections are available from page 37.
Measurements
The releases include a huge range of measurements. As for the protections, availability and combinations
vary for each version of the release:
Dip Touch
DISTRIBUTION GENERATORS
Dip Touch Hi-Touch G Touch G Hi-Touch
M. Dip M. Touch M. Touch M. Touch M. Touch
M.
Measuring
M.
Measuring
M.
Measuring
M.
Measuring
M. Hi-Touch M. Hi-Touch
The DIP measurements are available starting from page 44.

ABB SACE Emax 2 Specifications

General

Type	Air circuit breaker
Rated Current	800 A to 6300 A
Breaking Capacity	Up to 150 kA at 415 V AC
Frequency	50/60 Hz
Number of Poles	3, 4
Installation	Fixed or withdrawable
Standards	IEC 60947-2
Trip Unit	Ekip Touch, Ekip Hi-Touch
Communication	Modbus, Profibus, Ethernet
