ABB | SACE Emax 2

Accessories | 1 - Preliminary considerations

Accessories

1 - Preliminary considerations

Introduction

All the circuit-breakers have a series of electrical and mechanical accessories that can be applied according

to the circuit-breaker type, and a series of electronic accessories that can be applied according to the type

of Ekip release with which the circuit-breaker is equipped.

Accessory combination tables

The following table shows the possible combinations of the electrical and mechanical accessories:

Type of accessory Accessory Circuit-breakers Disconnectors

Electrical signalling

AUX 4Q S R

AUX 15Q R R

Ekip AUP (*) R R

Ekip RTC R R

S51 S -

S33 M/2 R R

Electrical control

YO-YC R R

YO2 R R

YU R R

M R R

YR R -

Safety mechanical

KLC and PLC R R

KLP and PLP (*) R R

SL (*) S S

DLC R R

Anti-racking-in lock S S

MOC R R

Protection mechanical

PBC R R

IP54 R R

HTC-LTC R R

PB R R

Interlocks MI R R

S: Standard. R: on request. (*): only for withdrawable version.

Continued on the next page

ABB SACE Emax 2 Installation, Operation And Maintenance Instructions
