ABB | SACE Emax 2
Ekip Dip protection release | 1 - Operator interface
35 | © 2014 ABB | 1SDH000999R0002 - L8569
LED
The LEDs are useful on Ekip Dip in order to distinguish and identify various types of information on the
protection release, the circuit-breaker and state of the line currents.
Operational conditions
The operation of the LED is determined by the power supply conditions of the release:
• With the release energized (by current sensors or by auxiliary power supply or by Ekip TT or by Ekip T&P
or by Ekip Bluetooth) the LEDs are operational for all the signals.
• With the release de-energized, the LEDs are limited to the signalling of the last switch-off or trip event
(combined with the check via iTest, described below).
NOTE: with the release off, the operation of the LEDs is guaranteed if the internal battery of
the release is working properly.
About
The LEDs combined with the protections provide various information, with different combinations of lighting
and blinking.
NOTE: all the combinations related to protection LED signals are described in chapter Self-
diagnosis and signalling , on page 46.
The power led provides information about the power status of the protection release:
• LED on (default configuration) fixed or blinking, signals release energized.
• LED off signals release de-energized.
NOTE: with Ekip T&P and Ekip Bluetooth modules and Ekip Connect software, it is possible
to configure how the power led functions (LED fixed or blinking).
Protections: thresholds
The thresholds of all the protections can be modified with various dip-switches, as specified on the serigraph
of the interface.
The values of the protections make reference to the current In, a nominal value of the release defined by the
Rating Plug.
IMPORTANT:
• Modification of the thresholds must be performed in the absence of protection alarms.
• Modifications carried out in alarm conditions are accepted by the release when resting
condition is restored (absence of protection alarms).
Protections: times
The times and the curves of the protections can be modified with various dip-switches, as specified on the
serigraph of the interface.
IMPORTANT:
• Modification of the times must be performed in the absence of protection alarms.
• Modifications carried out in alarm conditions are accepted by the release when resting
condition is restored (absence of protection alarms).
Settings
Two further settings are available:
• Neutral allows activation and adjustment of the protections on the neutral pole.
• Frequency allows the selection of the installation frequency.
