Allen-Bradley MicroLogix 1000 User Manual

Using Math Instructions
8–1
8 Using Math Instructions
This chapter contains general information about math instructions and explains how
they function in your logic program. Each of the math instructions includes
information on:
• what the instruction symbol looks like
• typical execution time for the instruction
• how to use the instruction
In addition, the last section contains an application example for a paper drilling
machine that shows the math instructions in use.
Math Instructions
Instruction
Purpose
Page
Mnemonic Name
Purpose
Page
ADD Add Adds source A to source B and stores the result in
the destination.
8–4
SUB Subtract Subtracts source B from source A and stores the
result in the destination.
8–5
MUL Multiply Multiplies source A by source B and stores the
result in the destination.
8–8
DIV Divide Divides source A by source B and stores the result
in the destination and the math register.
8–9
DDV Double Divide Divides the contents of the math register by the
source and stores the result in the destination and
the math register.
8–10
CLR Clear Sets all bits of a word to zero. 8–11
SQR Square Root Calculates the square root of the source and places
the integer result in the destination.
8–11
SCL Scale Data Multiplies the source by a specified rate, adds to an
offset value, and stores the result in the destination.
8–12
