A–10
Replacement Parts
Description Catalog Number
10 pt. ac input, 6 pt. relay output, ac power supply controller 1761-L16AWA
12 pt. ac and 4 pt. analog inputs, 8 pt . r elay and 1 pt. analog outputs, ac
powe
r s uppl y c ontroller
1761-L20AWA-5A
20 pt. ac input, 12 pt. relay output, ac power supply controller 1761-L32AWA
6 pt. dc input, 4 pt. relay output, ac power supply controller 1761-L10BWA
10 pt. dc input, 6 pt. relay output, ac power supply controller 1761-L16BWA
12 pt. dc and 4 pt. analog inputs, 8 pt . r elay and 1 pt. analog outputs, ac
powe
r s upply controller
1761-L20BWA-5A
20 pt. dc input, 12 pt. relay output, ac power supply controller 1761-L32BWA
6 pt. dc input, 4 pt. relay output, dc power supply controller 1761-L10BWB
10 pt. dc input, 6 pt. relay output, dc power supply controller 1761-L16BWB
12 pt. dc and 4 pt. analog inputs, 8 pt . r elay and 1 pt. analog outputs, dc
powe
r s upply controller
1761-L20BWB-5A
20 pt. dc input, 12 pt. relay output, dc power supply controller 1761-L32BWB
10 pt. dc input, 4 pt. FET and 2 pt . r elay outputs, dc powe r s upply
controller
1761-L16BBB
20 pt. dc input, 10 pt. FET and 2 pt . r elay outputs, dc powe r s upply
controller
1761-L32BBB
20 pt. ac input, 10 pt . t riac and 2 pt . r elay outputs, ac powe r s upply
controller
1761-L32AAA
Terminal doors for -L16AWA (2 doors per package) 1761-RPL-T16A
Terminal doors for -L16BWA (2 doors per package) 1761-RPL-T16B
Terminal doors for -L32AWA, -L32BWA, or -L32AAA (2 doors per
package)
1761-RPL-T32X
Communications door (1 door per package) 1761-RPL-COM
DIN rail latches (2 per package) 1761-RPL-DIN
2.00 m (6.56 ft) cable (DIN-to-DIN) for use with the MicroLogix 1000
HHP
1761-CBL-HM02
Hand-Held Programmer (includes 1761-CBL-HM02 communication
cable)
1761-HHP-B30
Memory module for 1761-HHP-B30 (stores 1 program) 1761-HHM-K08
Memory module for 1761-HHP-B30 (stores 8 programs) 1761-HHM-K64
Memory module door for 1761-HHP-B30 (1 door per package) 1761-RPL-TRM
