Scale Data (SCL)
When this instruction is true, the value at the source address is multiplied by the rate
value. The rounded result is added to the of
fset value and placed in the destination.
Note Anytime an underflow or overflow occurs in the destination file, minor err or bit
S:5/0 must be r eset. This must occur befor e the end of the curr ent scan to pr event
major err or code 0020 fr om being declar ed. This instruction can overflow befor e
the offset is added.
Entering Parameters
The value for the following parameters is between –32,768 to 32,767.
• Source can either be a constant or a word address.
• Rate is the positive or negative value you enter divided by 10,000. It can be a
constant or a word address.
• Offset can either be a constant or a word address.
Updates to Arithmetic Status Bits
With this Bit: The Controller:
S:0/0 Carry (C) is reserved.
S:0/1 Overflow (V)
sets if an overflow is detected; otherwise resets. On overflow,
minor error bit S:5/0 is also set and the value –32,768 or
32,767 is placed in the destination. The presence of an
overflow is checked before and after the offset value is
applied.➀
S:0/2 Zero (Z) sets when destination value is zero.
S:0/3 Sign (S) sets if the destination value is negative; otherwise resets.
➀
If the result of the Source times the Rate, divided by 10000 is greater than 32767, the SCL instruction overflows,
causing error 0020 (Minor Error Bit), and places 32767 in the Destination. This occurs regardless of the current
offset.
Execution Times
(µsec) when:
True False
169.18 6.78
SCL
SCALE
Source
Rate [/10000]
Offset
Dest
