Publication 1785-UM012D-EN-P - July 2005
11-26 Communicating with Devices on an Ethernet Network
Fixed display formats - float files are always output in floating point
format (“C”%g format). String files are always output as a null
terminated text string. Binary files are always output as four binary
nibbles. ASCII files are displayed in a memory dump format.
Importing User Page Files to the PLC-5 Controller
Use RSLogix5 to import user page files to the PLC-5 ASCII files:
1. In the Project folder (under Data Files folder), right-click on the ASCII
file where you will import the user page file, and choose Properties.
2. Click on Import HTML.
3. Use the browser to locate the user page file you want to import.
4. Double-click on the file to select it and click OK.
5. Repeat this process for each user page file.
6. When all user page files have been imported, go online with your PLC-5
controller.
