Publication 1785-UM012D-EN-P - July 2005
Processor Status File B-11
S:36-S:78
IMPORTANT
Setting inhibit bits in the processor status file (S:27, S:33, or
S:35) does not update inhibit bits in the I/O status file.
This Word Stores
S:36 - S:45 Reserved
S:46 PII program file number
S:47 PII module group
S:48 PII bit mask
S:49 PII compare value
S:50 PII down count
S:51 PII changed bit
S:52 PII events since last interrupt
S:53 STI scan time (in ms)
S:54 STI maximum scan time (in ms)
S:55 PII last scan time (in ms)
S:56 PII maximum scan time (in ms)
S:57 User program checksum
S:58 Reserved
S:59 Extended-local I/O channel discrete transfer scan (in ms)
S:60 Extended-local I/O channel discrete maximum scan (in ms)
S:61 Extended-local I/O channel block-transfer scan (in ms)
S:62 Extended-I/O channel maximum block-transfer scan (in ms)
S:63 Protected controller data table protection file number
S:64 The number of remote block-transfer command blocks being used
by channel pair 1A/1B.
S:65 The number of remote block-transfer command blocks being used
by channel pair 2A/2B.
S:66 Reserved.
