Publication 1785-UM012D-EN-P - July 2005

E-8 Switch Setting Reference

(1771-ASB Series C and D) I/O Rack Number -

without Complementary I/O

Rack 1 2 3 4 5 6

01 on on on on on off

02 on on on on off on

03 on on on on off off

04 on on on off on on

05 on on on off on off

06 on on on off off on

07 on on on off off off

10 on on off on on on

11 on on off on on off

12 on on off on off on

13 on on off on off off

14 on on off off on on

15 on on off off on off

16 on on off off off on

17 on on off off off off

20 on off on on on on

21 on off on on on off

22 on off on on off on

23 on off on on off off

24 on off on off on on

25 on off on off on off

26 on off on off off on

27 on off on off off off
