Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019 209

Chapter 10

Axis Configuration Examples for the

PowerFlex 527 Drive

This chapter provides example axis configurations when using a PowerFlex®

527 drive.

The following examples are typical axis-configuration applications for the

PowerFlex 527 drive:

• Frequency Control with No Feedback

• Velocity Control with Motor Feedback

• Position Control with Motor Feedback

Topic Page

Example 1: Frequency Control with No Feedback 210

Example 2: Velocity Control with Motor Feedback 214

Example 3: Position Control with Motor Feedback 217
