272 Rockwell Automation Publication MOTION-UM003K-EN-P - January 2019

Chapter 12 Homing

Scaling

Scaling parameters changes can potentially generate an APR fault because

internal constants computed from these two parameters can generate a motion

resolution change. If this change happens, an APR fault is generated.

Online Scaling

Any change or SSV message that results in a motion resolution change can

generate an APR fault.
