NetLinx Programming
100
NX-Series Controllers - WebConsole & Programming Guide
PoE SEND_COMMANDs
The NX-4200 has 4 ICSLAN ports, each of which feature Power-over-Ethernet (PoE). The ports are numbered 1-4. The following
PoE SEND_COMMANDs program the ICSLAN ports on the controller.
NOTE: Note: These commands are not compatible with Massio ControlPads.
PoE SEND_COMMANDs
Command Description
GET CLASS Retrieve the class type of the device connected via PoE. This command receives a COMMAND event of ’DISABLED’, ’NO
DEVICE’, or ’CLASS x DEVICE’, with x being a value from 0 to 4.
Syntax:
SEND_COMMAND <DEV>,"'GET CLASS'"
Example:
SEND_COMMAND PoE_24,"'GET CLASS'"
GET
CURRENT
Retrieve the current of the device connected via PoE. This command receives a COMMAND event with the number in
milliamps (mA).
Syntax:
SEND_COMMAND <DEV>,"'GET CURRENT'"
Example:
SEND_COMMAND PoE_24,"'GET CURRENT'"
GET FAULT Retrieve the type of fault on the PoE port. This command receives a COMMAND event of ’DISABLED’, ’NONE’, ’UNDER-
VOLTAGE / OVER-VOLTAGE’, ’CURRENT OVERLOAD’, ’LOAD DISCONNECT’, MAX POWER EXCEEDED,’ or ’POE NOT
AVAILABLE’.
Syntax:
SEND_COMMAND <DEV>,"'GET FAULT'"
Example:
SEND_COMMAND PoE_24,"'GET FAULT'"
GET STATUS Retrieve the status of the PoE port. This command receives a COMMAND event of ’STATUS: NORMAL’ or, ’STATUS: FAULT’.
Syntax:
SEND_COMMAND <DEV>,"'GET STATUS'"
Example:
SEND_COMMAND PoE_24,"'GET STATUS'"
GET
VOLTAGE
Retrieve the current draw on the PoE port. This command receives a COMMAND event with the number in volts.
Syntax:
SEND_COMMAND <DEV>,"'GET VOLTAGE'"
Example:
SEND_COMMAND PoE_24,"'GET VOLTAGE'"
SET FAULT
DETECT OFF
Disables fault detection on the PoE port. Fault detection is turned on by default.
Syntax:
SEND_COMMAND <DEV>,"'SET FAULT DETECT OFF'"
Example:
SEND_COMMAND PoE_24,"'SET FAULT DETECT OFF'"
SET FAULT
DETECT ON
Enables fault detection on the PoE port. Fault detection is turned on by default.
Syntax:
SEND_COMMAND <DEV>,"'SET FAULT DETECT ON'"
Example:
SEND_COMMAND PoE_24,"'SET FAULT DETECT ON'"
SET POWER
OFF
Disables PoE to the port. PoE is turned on by default.
Syntax:
SEND_COMMAND <DEV>,"'SET POWER OFF'"
Example:
SEND_COMMAND PoE_24,"'SET POWER OFF'"
SET POWER
ON
Enables PoE to the port. PoE is turned on by default.
Syntax:
SEND_COMMAND <DEV>,"'SET POWER ON'"
Example:
SEND_COMMAND PoE_24,"'SET POWER ON'"
