Ansul AUTOPULSE IQ-301 User Manual

Terminal Interface Protocol Operating Modes
170 IQ-301 PN 50036:F 10/29/2001
Table 62 below summarizes the functions available with the Local Terminal mode:
Table 62 LocT Functions
I.2.2 Local Monitor Mode (LocM)
Functions, passwords, and special requirements of Local Monitor Mode (LocM) are:
Functions: Read Status, Alter Status, and Control Functions.
Passwords: User-defined password for Alter Status and Control functions.
Requirements: Password security feature for Control Functions eliminates the need
for mounting the CRT-2 in an enclosure.
Table 63 summarizes the functions available with the Local Monitor mode:
Table 63 LocM Functions
I.2.3 Remote Terminal Mode (RemT)
Functions, passwords, and special requirements of Remote Terminal Mode (RemT) are:
Functions: Read Status only. See Table 64.
Function Lets you...
Read Status • Display the status of an individual point (detector, module, panel circuit, or
zone)
• Display a list of all the points in alarm or trouble
• Display a list of all programmed points in the system
• Step through the history buffer event by event
• Display the entire history buffer
Alter Status • Disable/Enable an individual point
• Change the sensitivity of a detector
• Clear the verification counter of all detectors
• Clear the entire history buffer
• Set the AWACS™ alert and action levels
Control
Functions
• Acknowledge
• Alarm Silence
• System Reset
• Drill
Function Lets you...
Read Status • Display the status of an individual point (detector, module, panel circuit, or
zone)
• Display a list of all the points in alarm or trouble.
• Display a list of all programmed points in the system
• Step through the history buffer event by event
• Display the entire history buffer
Alter Status* • Disable/Enable an individual point
• Change the sensitivity of a detector
• Clear the verification counter of all detectors
• Clear the entire history buffer
• Set the AWACS™ alert and action levels
Control
Functions*
• Acknowledge
• Alarm Silence
• System Reset
• Drill
*Requires the user defined password for access.
