R5906112 /09 UDX series 169
10.6 GSM configuration
Only possible when a GSM module with SIM card is installed in the projector.
What can be done ?
To configure the projector software with the installed SIM card, a correct PIN code (4digits) must be entered.
As the PIN code cannot be checked with the one on the SIM card, ensure to enter the correct PIN
code.
When your SIM card is blocked, you have to remove the SIM card from the GSM module and to
insert the SIM card in a mobile phone so that you can enter the PUK code to unblock the SIM card.
How to activate
1. In the main menu, select System Settings → Communication → GSM.
Image 10-25: Communication menu, GSM
The GSM pin code input menu is displayed. The current configured PIN code is indicated next to Pin input
field. If the code is still the same, it is not necessary to enter the PIN code again. If it is a PIN code, continue
with next step.
Image 10-26: Enter PIN code
2. Enter the 4 digits of the pin code and select APPLY and click OK.
