C.5 Overview video timings HDBaseT inputs
Overview
The following standard video formats are available for the projector.
Note: support for refresh rates 24.00, 30.00, 60.00 Hz automatically includes support of 1/1.001 x those
refresh rates.
Video timing
(active pixels x active lines)
Vertical refresh rate (Hz)
Available layout modes, other
than standard layout (1 x 1
layout)
640 x 480 60
720 x 480 60
720 x576 50
800 x 600 60
1024x 768 60
1280 x720 50
1280 x 720 60
1280 x 800 60
1280 x 960 60
1280 x1024 60
1400 x 1050 60
1600 x 1200 60
1920 x 1080 24
1920 x 1080 25
1920 x 1080 30
1920 x 1080 50
1920 x 1080 60
1920 x 1200 50
1920 x 1200 60
1920 x 2160 50 2 Column mode (2 x 1 layout)
1920 x 2160 60 2 Column mode (2 x 1 layout)
2048 x 1080 24
2048 x 1080 25
2048 x 1080 30
2048 x 1080 48
2048 x 1080 50
2048 x 1080 60
2048 x 2160 50 2 Column mode (2 x 1 layout)
2048 x 2160 60 2 Column mode (2 x 1 layout)
2560 x 1600 50
2560 x 1600 60
3840 x 2160 24
Overview video timings for video interfaces
