R5906112 /09 UDX series 85
6.3 Connector Settings
About Connector Settings
The Connector Settings menu allows you to change settings for each input connector of the projector.
By default all options for every connector are set to automatic, together with the native Extended Display
Identification Data (EDID).
When entering the menu for each input connector, you can change the following:
• Color Space
• Signal Range
• EDID
How to configure a connector
1. Press Menu to activate the menus and select Source.
Image 6-6: Select Source
2. Press OK.
The Select Source menu is displayed with the actual available sources filled out.
3. Scroll down to the bottom of the list of available sources and select Connector Settings.
Image 6-7: Source menu, Connector Settings
The available input connectors are displayed.
Image 6-8: Select source
4. Select the desired connector.
The Connector Settings menu for this connector will be displayed.
GUI – Source
