D.1 DMX chart input board positioning
About the input boards
6 Input selection ranges are reserved in the DMX chart per input board location (named L1 and L2). With the
current version of DMX support, it is important to take into account to keep the input boards in their original
slots.
Image D-1
1 Slot L1, here filled with the Quad combo Input board
2 Slot L2, here filled with the Quad DP 1.2 Input board
DMX chart
