Barco UDX Series User Manual

R5906112 /09 UDX series238
D.3 DMX chart, Extended
Overview
Cha-
nnel
Function Value Default Actions
1 Shutter + Intensity 0 - 7 255 Close shutter
8 - 255 Adjust intensity
2 Brightness 0 - 255 128 Adjusts the brightness between 0 and 100% on input.
3 Contrast 0 - 255 128 Adjusts the contrast between 0 and 100% on input
4 Input selection 0 - 7 0 No function
8 - 15 Activate first profile preset (If held for 1 second)
16 - 23 Activate second profile preset (If held for 1 second)
24 - 31 Activate third profile preset (If held for 1 second)
32 - 39 Activate fourth profile preset (If held for 1 second)
40 - 47 Activate fifth profile preset (If held for 1 second)
48 - 55 Activate sixth profile preset (If held for 1 second)
56 - 63 Activate seventh profile preset (If held for 1 second)
64 - 71 Activate eighth profile preset (If held for 1 second)
72 - 79 Activate ninth profile preset (If held for 1 second)
80 - 87 Activate tenth profile preset (If held for 1 second)
88 - 95 Select input 1: HDMI Input (If held for 1 second)
12
96 - 103 Select input 2: DisplayPort Input (If held for 1 second)
12
104 - 111 Select input 3: SDI Input A (If held for 1 second)
12
112 - 119 Select input 4: SDI Input B (If held for 1 second)
12
120 -
127
Select input 5: HDBaseT Input 1 (if held for 1 second)
12
128 -
135
Select input 6: Quad SDI input (if held for 1 second)
12
136 -
143
Select input 7: Quad DP board Input A (if held for 1 second)
13
144 -
151
Select input 8: Quad DP board Input B (if held for 1 second)
13
152 -
159
Select input 9: Quad DP board Input C (if held for 1 second)
13
160 -
167
Select input 10: Quad DP board Input D (if held for 1 second)
13
168 -
175
Select input 11: Quad DP board Inputs A-B (if held for 1
second)
13
176 -
183
Select input 12: Quad DP board quad column mode (if held for
1 second)
13
184 -
255
Reserved for future functionality
5 Focus (MSB) 0 - 255 128 Set coarse lens focus adjustment
14
6 Focus (LSB) 0 - 255 128 Set fine lens focus adjustment
14
7 Zoom (MSB) 0 - 255 128 Set coarse lens zoom adjustment
14
8 Zoom (LSB) 0 - 255 128 Set fine lens zoom adjustment
14
9 Lens shift vertical
(MSB)
0 - 255 128 Set coarse lens shift in vertical direction
10 Lens shift vertical
(LSB)
0 - 255 128 Set fine lens shift in vertical direction
11 Lens shift horizontal
(MSB)
0 - 255 128 Set coarse lens shift in horizontal direction
12 Lens shift horizontal
(LSB)
0 - 255 128 Set fine lens shift in horizontal direction
DMX chart
14: Only when lens has been calibrated
