R5906113 /08 UDX 121
Control XLR wired + IR, RS232, Wifi** (opt), GSM** (opt)
Network connection 10/100 base-T, RJ-45 connection, Wifi** (optional)
Power requirements 120-160V (reduced power) / 200-240V (+/- 10%), 20A, 50-60Hz
Max. power consumption 2,900 W nom / 3,100 W max. / STBY less than 10 W
Noise level (typical at 25°C/
77°F)
52dB(A)
Operational ambient
temperature
0-40°C / 32°-104°F
Operational humidity 0-80% (non condens)
Dissipation BTU Max. 9,895 BTU/h
Dimensions (WxLxH) 660 x 830 x 350 mm / 25.95 x 32.7 x 13.78 inches
Shipping Dimensions (WxLxH) 800 x 1200 x 685 mm / 31.49 x 47.24 x 26.96 inches
Weight 92kg (202 lbs)/shipping weight from factory: 110kg (242 lbs)
Standard accessories Power cord, wireless/XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1 complies with FCC rules &
regulations, part 15 Class A and CE EN55032 Class A, Rohs
Warranty 3 years
* +/- 10%
A.6 Specifications of the UDX-W26
Specifications
Projector type WUXGA 3-chip DLP digital projector
Technology 0.96" DMD™ x3
Resolution 1,920 x 1,200
Brightness 26,000 center lumens* / 25,000 ansi lumens / 28,000 ISO
Contrast ratio 2,000:1
Brightness uniformity 95%
Aspect ratio 16:10
ScenergiX Horizontal and vertical edge blending
Lenses TLD+ 0.37:1 ; 0.65:1 ; 0.73:1 ; 0.85:1 ; 1.2:1 ; 1.25 -1.6:1 ; 1.5-2.0:1 ; 2.0-
2.8:1 ; 2.8-4.5:1 ; 4.5-7.5:1 ; 7.5-11.5:1
Optical lens shift Vertical between -100% to +130%, depending on lens
Horizontal up to +/- 40%, depending on lens
Motorized zoom and focus (with lens memory on TLD lenses)
Motorized lens shift (with position memory on all lenses)
Color correction P7
Light source Laser phosphor with inorganic phosphor wheel
Light source lifetime 40,000 hrs
Specifications
