Barco UDX Installation Manual

R5906113 /08 UDX138
Video timing
(active pixels x active
lines)
Vertical refresh rate
(Hz)
8
Type Port Type
1920 x 1080 25 HD-SDI Single Link & Quad Link
1920 x 1080 30 HD-SDI Single Link & Quad Link
1920 x 1080 50 3G-SDI Single Link & Quad Link
1920 x 1080 60 3G-SDI Single Link & Quad Link
1920 x 1200 50 3G-SDI “BarcoLink” Single Link & Quad Link
1920 x 1200 59.94 3G-SDI “BarcoLink” Single Link & Quad Link
1920 x 1200 60 3G-SDI “BarcoLink” Single Link & Quad Link
2048 x 1080 50 3G-SDI Single Link & Quad Link
2048 x 1080 60 3G-SDI Single Link & Quad Link
3840 x 2160 50 12G-SDI
9
Single Link
3840 x 2160 60 12G-SDI
9
Single Link
3840 x 2400 50 12G-SDI “BarcoLink 4k”
9
Single Link
3840 x 2400 59.94 12G-SDI “BarcoLink 4k”
9
Single Link
3840 x 2400 60 12G-SDI “BarcoLink 4k”
9
Single Link
4096 x 2160 50 12G-SDI
9
Single Link
4096 x 2160 60 12G-SDI
9
Single Link
C.3 Overview video timings HDMI 2.0 inputs
Overview
The following standard video formats are available for the projector.
Note: support for refresh rates 24.00, 30.00, 60.00 Hz automatically includes support of 1/1.001 x those
refresh rates
Video timing
(active pixels x active lines)
Vertical refresh rate (Hz) 3D support?
640 x 480 60
720 x 480 60
720 x576 50
800 x 600 60
1024x 768 60
1280 x720 50 Frame packing
Top – bottom
1280 x 720 60 Frame packing
Top – bottom
1280 x 800 60
Overview video timings for video interfaces
8: Support for refresh rates 24.00, 30.00 and 60.00 Hz automatically includes support of 1/1.001 x those refresh rates.
9: 12G SDI board only, and only on Channel A
