R5906113 /08 UDX 31
Installation
Download first the reference manual and follow the installation instructions as written in this manual.
2.8 External cooler and hoses
Introduction
For functionality and reliability, the UDX projector requires accurate temperature control and cooling.
Therefore a liquid cooling system is provided in the projector.
If the option is chosen to have an external cooling system instead of an integrated cooling system, the cooling
circuit inside of the projector is connected to an external cooler via hoses. Only coolers and hoses exclusively
developed for this application and approved by Barco are allowed to be used in this setup.
The cooler is controlled by the projector and ensures that the ambient temperature of the laser banks,
phosphor wheel and diffuser wheel are within specs.
Image 2-13
2.9 Laser range finder & camera kit
WARNING: Laser Radiation — Do not stare into laser ranging beam, Class 2 IEC EN 60825-1:2014
Introduction
A laser range finder & USB camera kit has been provided to help multiple installations of the same projector.
By a simple button press, you can measure the distance between the projector and the projected surface.
Image 2-14: Laser range & USB camera module
Installation preparations
