R5906113 /08 UDX124
Control XLR wired + IR, RS232, Wifi (opt)*, GSM (opt)*
Network connection 10/100 base-T, RJ-45 connection, Wifi (optional)*
Power requirements 120-160V (reduced power)/ 200-240V (+/- 10%), 20A, 50-60Hz (reduced
power on 110v)
Max. power consumption 1,900 W @ 230 volts/ STBY less than 10W
Noise level (typical at 25°C/
77°F)
49 dB(A)
Operational ambient
temperature
0°-40°C/ 32°-104°F (45°C reduced power)
Operational humidity 0-80% (non condens)
Dissipation BTU Max. 6,600 BTU/h
Dimensions (WxLxH) 660 x 830 x 350 mm (25.98 x 32.67 x 13.77")
Shipping Dimensions (WxLxH) 800 x 1,200 x 685 mm / 31.49 x 47.24 x 26.96 inches
Weight 87.5kg (193 lbs)/shipping weight from factory: 105kg (231 lbs)
Standard accessories Power cord, wireless/XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1 complies with FCC rules &
regulations, part 15 Class A and CE EN55032 Class A, Rohs
Warranty 3 years
* Software upgradeable, please contact your local authorized Barco sales
representative
A.8 Specifications of the UDX-U40
Specifications
Projector type UXGA 3-chip DLP digital projector
Technology 0.98 DMD™ x3
Resolution 1600 x 1200
Brightness 37,500 center lumen*/ 36,500 ansi lumens / 40,000 ISO
Contrast ratio 2,000:1
Brightness uniformity 95%
Aspect ratio 4:3
ScenergiX Horizontal and vertical edge blending
Lenses TLD+ 0.37, 0.65-0.85, 0.8-1.16:1 ; 1.25-1.6:1 ; 1.5-2.0:1 ; 2.0-2.8:1 ; 2.8-
4.5:1 ; 4.5-7.5:1 ; 7.5-11.5:1
Optical lens shift Vertical between -100% to +130%, depending on lens
Horizontal up to +/- 40%, depending on lens
Motorized zoom and focus (with lens memory on TLD lenses)
Motorized lens shift (with position memory on all lenses)
Color correction P7
Light source laser phosphor with inorganic phosphor wheel
