Barco UDX Installation Manual

R5906113 /08 UDX 69
2D 2 column mode (2x1
layout)
• 1920 x 2160 @60 Hz
• 1920 x 2160 @120 Hz
• 1920 x 2400 @60 Hz
• 2048 x 2160 @60 Hz
• 2048 x 2160 @120 Hz
2D 4 quadrant mode (2x2
layout)
• 960 x 1080 @120 Hz
• 960 x 1200 @120 Hz
• 1280 x 1080 @60 Hz
• 1280 x 1080 @120 Hz
• 1280 x 1600 @60 Hz
• 1280 x 1600 @120 Hz
• 1920 x 1080 @120 Hz
• 1920 x 1200 @120 Hz
• 2048 x 1080 @120 Hz
2D 4 column mode (4x1
layout)
• 960 x 2160 @120 Hz
• 960 x 2400 @120 Hz
• 1024 x 2160 @60 Hz
Active
3D
Standard layout (1x1
layout)
• 1600 x 1200 @120 Hz
• 2560 x 1080 @120 Hz
• 2560 x 1600 @120 Hz
Active
3D
2 column mode (2x1
layout)
1920 x 2160 @120 Hz
Active
3D
4 quadrant mode (2x2
layout)
• 1920 x 1080 @120 Hz
• 1920 x 1200 @120 Hz
• 2048 x 1080 @120 Hz
Active
3D
4 column mode (4x1
layout)
• 960 x 2160 @120 Hz
• 960 x 2400 @120 Hz
• 1024 x 2160 @120 Hz
Passive
stereo
Standard layout (1x1
layout)
3840 x 2160 @60 Hz
Passive
stereo
2 column mode (2x1
layout)
1920 x 2160 @60 Hz
Native video
timings
• UDX-U-series: 1600 x 1200 @60 Hz
• UDX-W-series: 1920 x 1200 @60 Hz
• UDX-4k-series: 3840 x 2400 @60 Hz
6.7 Input source connections – SFP Input Board
The Barco SFP Input Board has been designed and tested to work alongside the Barco SFP Output
Board.
However, it is possible that the SFP Input board can also work with other third-party devices that
support 12G over fiber. Due to the many third-party options available on the market, the input board
could not be tested for every option available.
SFP input board
To connect 12G SDI over fiber.
The input board is delivered without any connector. It is up to the customer to buy the necessary connectors,
transceivers and cables. These parts can be mounted on the indicated places on the front panel of the board.
