BMW F 800 GS User Manual

NOTICE
The brake fluid level in the brake-
fluid reservoir drops due to brake
pad wear.
Rear brake fluid level (vi-
sual check)
Brake fluid, DOT4
You should never allow the
brake fluid level to drop below
the MIN mark.
If brake fluid level falls below the
approved level:
Have the defect corrected as
soon as possible by an autho-
rized workshop, preferably an
authorized BMW Motorrad re-
tailer.
Clutch
Check clutch function
Pull back the clutch lever.
Pressure point must be clearly
perceptible.
If no clear pressure point can be
felt:
Have the clutch checked by an
authorized workshop, preferably
an authorized BMW Motorrad
retailer.
Checking clutch play
Actuate the clutch lever until
resistance can be felt. Observe
cut-out 1 in the handlebar fit-
ting.
The edge of cable mount 2
should move to the edge of
handlebar fitting 3.
Clutch cable play
0.12...0.2 in (3...5 mm) (Han-
dlebars in straight-ahead posi-
tion)
9
100
z Maintenance

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
