BMW F 800 GS User Manual

Press lock housing 2 upward
while making sure that claw
grips around carrier.
To lock lock, turn key clock-
wise and remove.
Maximum payload and
maximum speed
Observe maximum payload and
top speed as indicated on label
in Topcase.
If you cannot find your combina-
tion of motorcycle and topcase
on the label, contact your BMW
Motorrad Retailer.
The following values apply to the
combination described here:
Maximum speed limit for
driving with a Topcase
max 112 mph (max 180 km/h)
Payload of Topcase
max 11 lbs (max 5 kg)
Additional headlight
with additional LED
headlight
OA
Operating auxiliary
headlight
NOTICE
The auxiliary headlights are
approved for use as fog lights
and may only be used in poor
weather conditions. Comply with
the country-specific road traffic
regulations.
Start engine.
Press button 1 to switch on
the auxiliary headlights.
The indicator lamp of
the auxiliary headlights is
switched on.
If the engine is switched off
while the auxiliary headlights
are on, then they will automat-
ically resume operation when
the engine is restarted.
Press button 1 again to switch
off the auxiliary headlights.
10
142
z Accessories

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
