BMW F 800 GS User Manual

Electrical system
Main fuse 30 A, voltage regulator
Fuses All electrical circuits are electronically protected.
If an electronic fuse trips and de-energizes a cir-
cuit, the circuit is active as soon as the ignition is
switched on after the fault has been rectified.
Electrical rating of onboard sockets 5 A
Battery
Battery design AGM (Absorptive Glass Mat) battery.
Battery voltage 12 V
Battery capacity 12 Ah
Spark plugs
Spark plugs, manufacturer and designation NGK DCPR 8 E
Electrode gap of spark plug 0.04...0.04 in (0.9...1.0 mm), new
Light sources
Bulb for high-beam headlight H7 / 12 V / 55 W
Bulbs for low-beam headlight H7 / 12 V / 55 W
Bulb for parking light W5W / 12 V / 5 W
Bulb for taillight/brake light LED
12
159
z Technical data

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
