BMW F 800 GS User Manual

Overview
with anti-theft alarm system
(DWA)
OE
General information on
DWA
Any attempt to move the vehi-
cle, change its position, start it
without authorization, or discon-
nect the vehicle battery, results
in the alarm being triggered. The
sensitivity of the system is de-
signed so that minor vibrations of
the motorcycle do not trigger an
alarm. Each theft attempt is sig-
naled following activation of the
system acoustically with the siren
and optically with synchronized
flashing of all 4 turn indicators.
You can adjust the behavior of
your DWA in partial areas to
meet your needs.
Protection of motorcycle
battery
To protect the motorcycle bat-
tery and to maintain the start-
ing capability, the activated DWA
switches off automatically after
several days. However, it remains
active for at least 10 days.
Radio interference
Radio systems or devices which
transmit on the same frequency
as the remote control of the
DWA can interfere with its func-
tion. With corresponding prob-
lems point the remote control at
the motorcycle from a different
direction.
Controls
1 LED
2 Right-hand button ( 56)
3 Left-hand button (ribbed)
( 55)
Activation
with anti-theft alarm system
(DWA)
OE
5
54
z Alarm system

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
