For more extensive service op-
erations (such as wheel removal
and installation), BMW Motorrad
has put together a service tool kit
matched to your motorcycle. You
can purchase this tool kit from
your authorized BMW Motorrad
retailer.
Front wheel stand
Mount front wheel stand
ATTENTION
Use of the BMW Motorrad
front wheel stand without an
auxiliary stand
Component damage cause by
tipping over
Place the motorcycle on an
auxiliary stand before lifting
the front wheel with the
BMW Motorrad front-wheel
stand.
Place motorcycle on a suitable
auxiliary stand.
with center stand
OE
Place motorcycle on center
stand, ensuring that it is rest-
ing on a firm and level support
surface.
Use basic stand with tool
number (83 30 0 402 241) in
combination with front-wheel
adapter (83 30 0 402 242).
Loosen mounting bolts 1.
Push two mounts 2 outward,
continuing until front
suspension fits between them.
Adjust support pin to match
front suspension.
Use locating pins 3 to set front
wheel stand to desired height.
Center front wheel stand rela-
tive to front wheel and push it
against front axle.
9
93
z Maintenance

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
