Position locking claw 3 on case
carrier while holding case in
place.
Press lock housing 2 to side
while ensuring that claw grips
around bracket.
Turn key clockwise and re-
move.
Maximum payload and
maximum speed
Observe maximum payload and
maximum speed as indicated on
label in case.
If you cannot find your
combination of motorcycle and
case on the label, contact your
BMW Motorrad Retailer.
The following values apply to the
combination described here:
Maximum speed for rid-
ing with case
max 112 mph (max 180 km/h)
Payload per case
max 22 lbs (max 10 kg)
Aluminum Topcase
Topcase when driving
offroad
with aluminum Topcase
OA
When driving offroad, the Top-
case should be removed or the
back padding available as an op-
tional accessory should be used.
Open the Topcase
with aluminum Topcase
OA
Turn key 1 counterclockwise.
Press lock housing 2 upward
to release locking claw 3.
Pull locking claw 3 toward rear
and open lid.
Closing the topcase
with aluminum Topcase
OA
10
140
z Accessories

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
