BMW F 800 GS User Manual

Onboard computer
display
with onboard computer
OE
Mileage covered since
reaching the fuel reserve
( 34)
Average fuel consumption
Average speed
Current fuel consumption
Outside temperature
( 30)
Coolant temperature
Warning lights
Displays
Warnings are displayed with ap-
propriate warning lights.
Warnings for which no separate
warning lamp is available are in-
dicated by the 'universal' warn-
ing lamp 1 in conjunction with a
warning notice or a warning sym-
bol in the multifunction display.
The universal warning light lights
up in either yellow or red de-
pending on the urgency of the
warning.
Adjacent to the numerical data
display 2 a warning triangle 3
may also appear. These warn-
ings alternate with the odometers
( 40).
The universal warning light lights
up for the most urgent warning.
The following page contains a list
of potential warnings.
3
25
z Displays

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
