BMW F 800 GS User Manual

Payload per case
max 22 lbs (max 10 kg)
Topcase
Open the Topcase
with Topcase
OA
Turn key 1 in Topcase lock
into vertical position.
Hold down yellow locking de-
vice 2 and fold out carrying
handle 3.
Press yellow button 4 toward
front while pressing Topcase
lid upward.
Closing the Topcase
with Topcase
OA
Turn key in Topcase lock into
vertical position.
Close Topcase lid with firm
pressure.
ATTENTION
Folding down the carrying
handle when the case is
locked
Damage to the locking tab
Before folding down the car-
rying handle, make sure that
the slot of the topcase lock is
vertical.
Fold carrying handle 3 down.
Carrying handle audibly en-
gages.
10
135
z Accessories

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
