Damping
Setting
Damping must be adjusted to the
road conditions and the spring
preload.
A rough road surface requires
softer damping than a smooth
road surface.
An increase in spring preload
requires firmer damping, a re-
duction in spring preload re-
quires softer damping.
Adjusting damping on rear
wheel
Park motorcycle, ensuring that
support surface is firm and
level.
Adjust damping via adjusting
screw 1.
To increase damping, turn ad-
justing screw 1 in arrow direc-
tion H.
To decrease damping, turn ad-
justing screw 1 in arrow direc-
tion S.
Basic setting of rear
wheel rear-wheel damp-
ing
without Electronic
Suspension Adjustment
(ESA)
OE
Turn adjusting screw as far
as possible clockwise, then
turn back 1.5 turns. (One-up
without load)
Turn adjusting screw as far as
possible clockwise, then turn
back 1.5 turns. (One-up with
load)
Turn adjusting screw as far
as possible clockwise, then
turn back 1 turn. (Two-up with
load)
6
68
z Setting
