NOTICE
The adjusting screw is easier to
turn if you push the brake lever
forwards.
Spring preload
Setting
It is essential to set the spring
preload of the rear suspension to
suit the load carried by the mo-
torcycle. Increase spring preload
when the motorcycle is heavily
loaded and reduce spring preload
accordingly when the motorcycle
is lightly loaded.
Adjusting spring preload
at rear wheel
Remove seat ( 50).
Remove toolkit 2.
WARNING
Uncoordinated settings of
spring preload and spring
strut damping.
Poorer handling.
Adjust damping characteristic
to changed spring preload.
To increase spring preload,
turn adjustment wheel 1 clock-
wise using toolkit.
To decrease spring preload,
turn adjustment wheel 1 coun-
terclockwise using toolkit.
Basic setting of spring
preload, rear
Turn adjustment wheel coun-
terclockwise as far as possible.
(One-up without load)
Turn adjustment wheel as
far as possible counterclock-
wise, then 12 turns clockwise.
(One-up with load)
Turn adjuster wheel clockwise
up to stop. (Two-up and load)
Remount toolkit.
Install seat ( 50).
6
67
z Setting

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
