BMW F 800 GS User Manual

Activation with motion
sensor
The alarm function can be acti-
vated in 2 different ways:
Pressing the 1 button once
on the remote control. The
alarm function is enabled af-
ter 15 seconds. If switched
off more than one minute ago,
the 1 button must be pressed
for longer than one second.
Turning off the ignition (if pro-
grammed). The alarm function
is enabled after 45 seconds.
Activation is confirmed by two
flashes of the turn signals and
the sounding of two alarm tones.
Protection of the battery
in the control unit (DWA
disabled)
After approx. one hour in the
deactivated state, the DWA
switches off to protect the
battery. To activate the alarm
function after this period, the
ignition must be switched on and
then off again.
Motion sensor when
transporting the
motorcycle
If, for example, the motorcycle
is to be transported by train, it is
advisable to switch off the motion
sensor. The strong movements
could result in an accidental trig-
gering of the alarm.
Deactivating motion
sensor
Press button 1 of the remote
control again during the activa-
tion phase.
Turn indicators are illuminated
three times.
Alarm tone sounds three times.
Motion sensor is deactivated.
Alarm function
with anti-theft alarm system
(DWA)
OE
5
55
z Alarm system

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
