Lay on center fairing panel.
Make sure that three tabs 4
on left and right grip into side
panels.
Install four screws 2.
Install screws 1 on left and
right.
Install seat ( 50).
Jump-starting
ATTENTION
Current too high when jump-
starting the motorcycle
Cable fire or damage to the mo-
torcycle electronics
Do not jump-start the motor-
cycle using the power socket,
only via the battery terminal.
ATTENTION
Contact between crocodile
clips of jump leads and mo-
torcycle
Danger of short circuit
Use jump leads fitted with fully
insulated crocodile clips at both
ends.
ATTENTION
Jump-starting with a voltage
higher than 12 V
Damage to the motorcycle's
electronics
The battery of the donor mo-
torcycle must have a voltage of
12 V.
Removing center fairing panel
( 119).
Do not disconnect the battery
from the onboard electrical sys-
9
120
z
Maintenance
