BMW F 800 GS User Manual

Operating electrical
accessories
Additional devices connected to
onboard sockets can only be put
into operation when the ignition
is switched on. The accessory
remains operational if the igni-
tion is subsequently switched off.
Onboard sockets are switched off
approx. 15 minutes after switch-
ing off the ignition to reduce the
strain on the onboard electrical
system.
Additional devices with low
power consumption are possibly
not detected by the vehicle
electronics. In these cases,
onboard sockets are already
switched off shortly after the
ignition is switched off.
Cable routing
Observe the following when rout-
ing cable from power sockets to
additional devices:
Cables must not hinder the
rider's movement.
Cables must not restrict the
steering angle and driving char-
acteristics.
Cables must not become
trapped.
Luggage
Lashing down luggage
Route luggage belts between
motorcycle and along anti-slip
locks 1.
Route luggage belt 2 as shown
using example of a luggage roll.
Check piece of luggage for se-
cure hold.
Case
Open case
with case
OA
10
131
z Accessories

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
