BMW F 800 GS User Manual

Payload of Topcase
max 11 lbs (max 5 kg)
Aluminum case
Open case
with aluminum case
OA
Turn key 1 counterclockwise.
NOTICE
The case cover can be opened
with both the left and the right
latch.
Press lock housing 2 upward
to release locking claw 3.
Pull locking claw 3 to side and
open cover lid.
Close case
with aluminum case
OA
Close case lid.
Position locking claw 3 on lid.
Press lock housing 2 down-
ward while making sure that
claw grips into lid.
To lock, turn key clockwise and
remove.
Removing case lid
with aluminum case
OA
Open one lock of case lid.
Detach lid retaining cable 1.
Close case lid.
Open second latch of case lid.
Remove case lid.
Installing case lid
with aluminum case
OA
Lay case lid on case.
Close one lock of case lid.
10
138
z Accessories

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
