BMW F 800 GS User Manual

Have damaged rims checked
and, if necessary, replaced
by a specialist service facil-
ity, preferably an authorized
BMW Motorrad retailer.
Checking spokes
Make sure ground is level and
firm and park motorcycle.
Sweep across spokes with a
screwdriver handle or similar
item, paying attention to the
sound that they emit as you
proceed.
If the tone does not remain con-
sistent:
Have spokes checked by an
authorized service facility,
preferably an authorized
BMW Motorrad dealer.
Checking tire tread depth
WARNING
Riding with heavily worn
tyres
Risk of accident due to poorer
rideability
If necessary, replace the tyres
before the legally specified
minimum tread depth is
reached.
Make sure ground is level and
firm and park motorcycle.
Measure tire tread depth in
main tread grooves with wear
indicating marks.
NOTICE
Tread wear marks are integrated
into the main grooves on every
tire. If the tire tread has worn
down to the level of the marks,
the tire is completely worn. The
locations of the marks are indi-
cated on the edge of the tire, e.g.
by the letters TI, TWI or by an
arrow.
When the minimum tread depth
is reached:
Replace tires concerned.
Wheels
Tyre recommendation
For every size of tyre,
BMW Motorrad has tested and
approved certain makes as
roadworthy. BMW Motorrad
cannot evaluate the suitability of
other tyres, and can therefore
take no responsibility for their
driving safety.
BMW Motorrad recommends
only using the tyres tested and
approved by BMW Motorrad.
The permissible maximum speed
and load capacity figures must
be complied with (see "Technical
Data").
Observe the notes on maximum
speed with studded or winter
tyres ( 71).
9
103
z Maintenance

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
