BMW F 800 GS User Manual

ASC function is activated.
If the coding plug is not in-
stalled, the ignition can also be
turned off and then on again as
an alternative.
NOTICE
If the ASC indicator and warning
light lights up after the ignition is
turned off and on and then riding
continues at more than 5 km⁄h,
an ASC fault has occurred.
Electronic suspension
adjustment (ESA)
with Electronic Suspension Ad-
justment (ESA)
OE
Adjustment options
You can use the ESA Electronic
Suspension Adjustment feature
to adapt damping on the rear
wheel to the road surface. Three
damping settings are available.
Calling up settings
Switch on ignition.
Press button 1 to display cur-
rent adjustment.
The adjusted damping is shown
in the multifunction display, in
area 1. The displays provide the
following information:
COMF: Comfortable damping
NORM: Normal damping
SPORt: sporty damping
The display is automatically
hidden again after a short time.
Adjust the chassis
Switch on ignition.
Press button 1 to display cur-
rent adjustment.
4
46
z Operation

BMW F 800 GS Specifications

General

Displacement	798 cc
Bore x Stroke	82 mm x 75.6 mm
Power	85 hp (63 kW) at 7, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Upside-down telescopic fork, Ø 43 mm
ABS	Standard
Compression Ratio	12.0:1
Final Drive	Chain
Engine Type	Liquid-cooled, 4-stroke, parallel twin
Torque	83 Nm (61 lb-ft) at 5, 750 rpm
Transmission	6-speed
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Twin disc, 300 mm, 2-piston floating calipers
Rear Brake	Single disc, 265 mm, single-piston floating caliper
Fuel Capacity	16 liters
Seat Height	880 mm
Wet Weight	214 kg
Dry Weight	421 lbs (191 kg)
Frame	Tubular steel frame
Length	2, 320 mm
Width	945 mm
Height	1, 350 mm
Wheelbase	1, 578 mm
